YE2 SERIES THREE PHASE ELECTRIC MOTOR

Efficiency:IE 2

work mode:S1

Frequency:50HZ/60HZ
Cooling method:IC411

AC Voltage:380/660 400/690V


  • Introduction

    YE2 Series motor 15 totally enclosed and fan cooling, three-phase squirrel cage induction motor, it is newly designed in conformity with the relevant rules of IEC & DI N42673 Standards.

    YE2 series motors have outstanding performance, such as high efficiency, energy saving, high starting torque, low noise, little vibration, reliable operation and easy maintenance, etc.

    YE2 series motors are widely used in many places , where do not exist combustible , explosive or corrosive gas , and without any special requirements , such as machine tools , pumps , fans , transport machinery , mixer. Agriculture machinery and food machines, etc.

    Notes: The Y connection for motor of 3kw and below. And delta connection for 4kw and above.
