AUTOJET Series Automatic Booster Systems

 IEC 60034-1 - IEC 335-1
- IEC 34-1 - ISO 2548

  • Introduction

  • Automatic high pressure groups coupled with selfpriming jet pumps.

  • They are very silent and reliable and from a water system, to supply water from wells and in domestic high pressure groups


Features

  • Single phase power supply with capacitor
    permanently activated.
    Insulation class: B
    Protection: IP44
    Speed of rotation:2850rpm
    Continuous duty: S1

  • 24 Litres Cylindrical Tank with membrane.
    5 way brass: Connector(YJR5-G1"x50x80).
    Pressure Switch:
    Model SK-2(ON:1.38bar- OFF:2.76bar).
    Pressure Gauge: 6 bar
    Flexible hose:
    YJFM-F1"xM1"x 33x52

  • image.pngimage.png
