Introduction

horizontal multi-stage centrifugal pump are designed to work with clean water in domestic applications, irrigation, industry, etc. the pump body is made of stainless steel, so that they are of beautiful design. at the same time, they have the advantage of low noise, easy operation and reliable performance.

Pumps should be installed in a covered area, protected against the weather.

Features

Pump Body: stainless steel

Motor Housing: aluminum

Shaft: 45#  Steel /Stainless Steel

Impeller: Stainless Steel/PPO optional

Motor: closed, externally ventilated

Insulation Class: B/F

Protection Class: IP44 /IP54

Duty: continuously rated

Mechanical Seal: ceramic steatite/metalized carbon
